Precise Temperature Control & Independent Experiment
- Highly Uniform Thermal Cycling for Consistent and Reproducible Results
- Built-In Independent Control System Ensures:
- Each Experiment Runs Autonomously with No Impact from Other Assays
- No Risk of Data Loss due to Connection Failures or Software Issues
- Reliable Peltier-Based Temperature Control for Rapid Heating and Cooling
Medium Throughput With Fast Time-To-Result
- Designed for Medium-Scale Applications, Balancing High Efficiency with Flexibility
- Optimized Thermal Cycling for Rapid Amplification and Short Turnaround Times
- Ideal for Research Labs, Diagnostic Centers, and Biotech Companies
OST-EFFECTIVE & SCALABLE SOLUTION
- Efficient Power Usage and Optimized Consumable Consumption
- Compatible with Standard qPCR Reagents and Consumables
- Scalable for Small to Medium Laboratories looking for High-Performance Results
Intelligent Software With Multiple Data Analysis Modes
- User-Friendly Interface with Easy Experiment Setup and Monitoring
- Versatile Data Analysis Supports Various Analysis Modes:
- Multiplex Gene Expression Analysis
- Automated Baseline Correction and Threshold Setting for Enhanced Accuracy
Advanced Optical System With Fiber Optic Technology
- Supports up to 8 Fluorescent Channels, enabling Multiplex qPCR
Specification Table
| PRODUCT DESCRIPTION | PCR Instrument |
| SAMPLE CAPACITY | 8-Well, 0.2mL Block (per Module) |
| COMPATIBLE PLATES AND TUBES | Single Tube, 8-Well Strip Tube (Transparent) |
| EXCITATION SOURCE | LED |
| DETECTION METHOD | Photodiodes |
| DETECTION CHANNELS | 8 |
| AVERAGE HEATING AND COOLING RATE | 4°C/sec |
| MAXIMUM HEATING AND COOLING RATE | 6°C/sec |
| TEMPERATURE UNIFORMITY | ±0.25°C |
| DYNAMIC RANGE | 10 Logs of Linear Dynamic Range |
| OUTER DIMENSIONS (W X D X H) | 42cm x 33cm x 17cm |
