Real-time qPCR Instrument System-4 modules, 1well and 4 Channels each

SKU: AMQ-0404 MULTI

AMQ-0404 MULTI

AMQ-MINI is ideal for on-the-go molecular diagnostics, field testing, and rapid point-of-care applications. Among the smallest qPCR systems available, it features a single reaction well compatible with standard 0.2 mL PCR tubes, ultra fast ramping speeds, four fluorescence detection channels for multiplex analysis, and a wireless tablet-based control via Bluetooth ensures an intuitive, seamless experience without bulky computers or wired connections.

Key Features

Advanced Optical System With Fiber Optic Technology

• Supports up to 4 Fluorescent Channels, enabling Multiplex qPCR

Intuitive Software With Multiple Data Analysis Modes

• User-Friendly Interface with Easy Experiment Setup and Monitoring
• Versatile Data Analysis Supports Various Analysis Modes:
• Multiplex Gene Expression Analysis
• SNP Genotyping
• Automated Baseline Correction and Threshold Setting for Enhanced Accuracy

Fast Time-To-Result

• Designed for Multiple Applications, Balancing High Efficiency with Flexibility
• Optimized Thermal Cycling for Rapid Amplification and Shorter Turnaround Times

Cost-Effective & Scalable Solution

• Efficient Power Usage and Optimized Consumable Consumption
• Compatible with Standard qPCR Reagents and Consumables
• Scalable for Small to Medium Laboratories looking for High-Performance Results

Precise Temperature Control & Independent Experiment

• Highly Uniform Thermal Cycling for Consistent and Reproducible Results
• Built-In Independent Control System Ensures:
  • Each Experiment Runs Autonomously with No Impact from Other Assays
  • No Risk of Data Loss due to Connection Failures or Software Issues
  • Reliable Peltier-Based Temperature Control for Rapid Heating and Cooling

Applications

• Scalable: For Small to Medium Laboratories looking for High-Performance Results
• Ideal for Handling Diverse Sample Types and Time-Sensitive Analyses

Specification Table

PRODUCT DESCRIPTION	PCR Instrument with 7-Inch Touchscreen
SAMPLE CAPACITY	1-Well, 0.2mL Block (per Module)
COMPATIBLE PLATES AND TUBES	Single Tube (Transparent)
REACTION VOLUME	20-120 µL
EXCITATION SOURCE	LED
EXCITATION RANGE	475-670 nm
DETECTION METHOD	Photodiodes
DETECTION RANGE	515-680 nm
DETECTION CHANNELS	5
TEMPERATURE RANGE	4-100°C
AVERAGE HEATING AND COOLING RATE	5°C/sec and 6°C/sec
MAXIMUM HEATING AND COOLING RATE	7°C/sec
TEMPERATURE UNIFORMITY	±0.25°C
TEMPERATURE ACCURACY	±0.15°C
DYNAMIC RANGE	10 Logs of Linear Dynamic Range
OUTER DIMENSIONS (W X D X H)	30cm x 27cm x 25cm
WEIGHT	8kg
