Advanced Optical System With Fiber Optic Technology
- 4 Fluorescence Detection Channels
- Detect up to 4 Targets per Reaction, Reducing Reagent Use and Sample Volume
- Enables Multiplexing, Detecting up to 4 Different Targets per Well, Reducing Reagent Consumption and Increasing Throughput
Rapid Thermal Cycling
- Fast Ramping Rates: Utilizes Advanced Thermal Control Technology to Achieve Swift Heating and Cooling Cycles, Expediting the qPCR Process
- Precise Temperature Control: Maintains Accurate and Consistent Temperatures, Essential for Optimal Amplification Efficiency and Specificity
User-Friendly Tablet Interface With Bluetooth Connectivity
- Wireless Operation: Connects to a Tablet via Bluetooth, Eliminating Cumbersome Cables and Enhancing Portability
- Monitoring: Users can Observe Amplification Curves and Analyze Data in Facilitating Prompt Decision-Making
Cost-Effective Solution
- Affordable Pricing: Designed to be Budget-Friendly, this qPCR Instrument Lowers the Barrier to Entry for Advanced Molecular Diagnostics and Research
- Low Operating Costs: Efficient Energy Consumption and Minimal Maintenance Requirements Contribute to Reduced Long-Term Expenses
Compact And Portable Design
- Dimensions: Optimized for Space Efficiency, Ideal for Small Laboratories
- Weight: Only 2kg, Ensures Easy Transport and Setup in Various Environments
Specification Table
| PRODUCT DESCRIPTION | PCR Instrument |
| SAMPLE CAPACITY | 3-Well, 0.2mL Block |
| COMPATIBLE PLATES AND TUBES | Single Tube (Transparent) |
| REACTION VOLUME | 20-120 µL |
| EXCITATION SOURCE | LED |
| EXCITATION RANGE | 475-620 nm |
| DETECTION METHOD | Photodiodes |
| DETECTION RANGE | 515-670 nm |
| DETECTION CHANNELS | 4 |
| TEMPERATURE RANGE | 4-100°C |
| AVERAGE HEATING AND COOLING RATE | 5°C/sec |
| MAXIMUM HEATING AND COOLING RATE | 7°C/sec and 6°C/sec |
| TEMPERATURE UNIFORMITY | ±0.25°C |
| TEMPERATURE ACCURACY | ±0.15°C |
| DYNAMIC RANGE | 10 Logs of Linear Dynamic Range |
| OUTER DIMENSIONS (W X D X H) | 13cm x 13cm x 23cm |
| WEIGHT | 2kg |
