Anti-SLC4A1/CD233/Band 3 Antibody Picoband® (monoclonal, 5G2G7)

SKU: M01146-1

Size: 100 μg

Storage: At -20℃ for one year from date of receipt. After reconstitution, at 4℃ for one month. It can also be aliquotted and stored frozen at -20℃ for six months. Avoid repeated freezing and thawing.

Form: Lyophilized

Reactivity: Human

Applications: WB,IHC,Flow Cytometry

Application Details: Western blot, 0.25-0.5 μg/ml, Human
Immunohistochemistry(Paraffin-embedded Section), 2-5 μg/ml, Human
Flow Cytometry (Fixed), 1-3 μg/1x10⁶ cells, Human

Gene Name: SLC4A1

Specificity:

Background: Band 3 is also known as SLC4A1. The protein encoded by this gene is part of the anion exchanger (AE) family and is expressed in the erythrocyte plasma membrane, where it functions as a chloride/bicarbonate exchanger involved in carbon dioxide transport from tissues to lungs. The protein comprises two domains that are structurally and functionally distinct. The N-terminal 40kDa domain is located in the cytoplasm and acts as an attachment site for the red cell skeleton by binding ankyrin. The glycosylated C-terminal membrane-associated domain contains 12-14 membrane spanning segments and carries out the stilbene disulphonate-sensitive exchange transport of anions. The cytoplasmic tail at the extreme C-terminus of the membrane domain binds carbonic anhydrase II. The encoded protein associates with the red cell membrane protein glycophorin A and this association promotes the correct folding and translocation of the exchanger. This protein is predominantly dimeric but forms tetramers in the presence of ankyrin. Many mutations in this gene are known in man, and these mutations can lead to two types of disease: destabilization of red cell membrane leading to hereditary spherocytosis, and defective kidney acid secretion leading to distal renal tubular acidosis. Other mutations that do not give rise to disease result in novel blood group antigens, which form the Diego blood group system.

Immunogen: E.coli-derived human SLC4A1 (Position: E28-N365). Human SLC4A1 shares 75.7% and 74.5% amino acid (aa) sequence identity with and rat SLC4A1, respectively.

Clonality: Monoclonal

Contents: Each vial contains 4 mg Trehalose, 0.9 mg NaCl and 0.2 mg Na2HPO4.

Purification: Immunogen affinity purified.

Reconstitution: Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.

Reference: 1. Jarolim P, Palek J, Amato D, Hassan K, Sapak P, Nurse GT et al. (1991). Deletion in erythrocyte band 3 gene in malaria-resistant Southeast Asian ovalocytosis.Proc. Natl. Acad. Sci. U.S.A. 88 (24): 11022–6. 2. Schlüter K, Drenckhahn D (August 1986).Co-clustering of denatured hemoglobin with band 3: its role in binding of autoantibodies against band 3 to abnormal and aged erythrocytes. Proc. Natl. Acad. Sci. U.S.A. 83 (16): 6137–41.

Uniprot ID: P02730

Host: Mouse

Concentration: Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.

Conjugate:

Cross Reactivity: No cross-reactivity with other proteins.

Isotype: Mouse IgG2b

Phospho_site:

Clone Number: Clone: 5G2G7

Observed Molecular Weight: 102 kDa

Calculated Molecular Weight:

Gene ID: 6521

Protein Name: Band 3 anion transport protein

Gene Full Name: solute carrier family 4 member 1 (Diego blood group)

Synonyms: AE 1; AE1; Anion exchange protein 1; Anion exchanger 1; band 3; Band 3 anion transport protein; band 3/ AE1; CD233; SLC4A1
